Contact HTechView in 3D GalleryThe lowest priced wooden bike frame on the market. Designed and built by HTech Bikes, a lower price doesn't mean lower quality, the HTech Juncture come with the same level of build quality and craftsmanship as our premium frames without sacrificing HTech's signature smooth performance ride characteristics.
The Juncture is designed to be built as efficiently as possible while still allowing the levels of customisation expected from a small manufacturer. Built as the little brother of the HTech Aeriform the Juncture shares its base geometry and some design and construction features with the Aeriform. With its compact frame and short wheelbase lending to exceptional handling capabilities. Each Juncture frame uses HTech Bikes leading SCR technology creating a lighter yet stiffer frame unparalleled in this price bracket.
The Juncture is a jarrah frame and HTech Bikes most affordable all hardwood frame. Strong and stiff with exceptional pedalling efficiency and comfort. Showing quality performance hardwood frames don’t have to be expensive.
| Model | JU19 Juncture |
|---|---|
| Frame Technology | SCR |
| Wood Species | Jarrah |
| Frame Classification | Casual Road |
| Geometry | Fixed Size - Performance Frame |
| Cable Routing | Internal Mechanical |
| Brakes | Rim Caliper |
| Bottle Mounts | Two |
| Rear Dropouts | 130mm |
| Seatpost | 27.2mm |
| Headset | 1 1/8 |
| Fork | 1 1/8 |
| Bottom Bracket | 68mm, English Threaded (BSA) |
| Tyre Size | 28mm |
| Size | 50cm | 53cm | 56cm | 59cm |
|---|---|---|---|---|
| Stack | 549 | 567 | 585 | 604 |
| Reach | 358 | 367 | 376 | 384 |
| Seat Tube Angle | 75 | 74 | 73 | 72 |
| Top Tube | 505 | 530 | 555 | 580 |
| Head Tube | 145 | 160 | 175 | 195 |
| Head Tube Angle | 71 | 72 | 73 | 73 |
| Bottom Bracket Drop | 68 | 68 | 68 | 68 |
| Rear Centre | 420 | 420 | 420 | 420 |
Every HTech bike frame is built to order. We do not stock frames.
When you contact HTech Bikes about a frame order, you will be contacted by HTech Bikes to confirm the details of your order as soon as possible. The order will then be added to the frame build queue, you will be notified of the current build queue wait time.
The HTech Juncture is designed to be built as efficiently as possible leading to shorter frame build queue and build times. Frame construction will take 3-4 weeks depending on suppliers and other projects. Customisation and extras will take longer
When your new HTech wooden bike frame is ready, your frame will be shipped within the next few days.
